Asus ROG Crosshair VII Hero (Wi-Fi) Review
Nosotros received our sample of the Asus ROG Crosshair VII Hero Wi-Fi equally role of the press kit that AMD delivered for the launch of Ryzen 7 2700X and Ryzen v 2600X CPUs. Equally we expected, the Crosshair VII Hero is a high end motherboard that is loaded with overclocking features and while it looks and feels actually solid, our initial testing suggested that operation was nothing special.
This was pretty much the opposite of what nosotros expected from the ROG make, nonetheless it seemed unlikely Asus had made a primal mistake with the design and so nosotros decided to hold off with our review until Asus had the chance to update the BIOS as that tin can make a massive divergence to the way a motherboard behaves. In the intervening period Asus has issued a steady stream of updates including a BIOS that supports a new version of AGESA, which is the sort of matter we expect, and so Asus sent over a Operation BIOS that looked very interesting.
Sentry the video via our VIMEO Aqueduct (Beneath) or over on YouTube at 2160p Hither
Specification:
CPU: AM4 Socket AMD Ryzen processor
Chipset: AMD X470
Memory: 4x DDR4 DIMM sockets supporting up to 64GB of organisation retentivity
Dual aqueduct memory architecture
Back up for up to DDR4 3400MHz+(O.C.)
Multi-GPU Support for NVIDIA two-way SLI and AMD iii-way CrossFireX
PCI Slots:
two ten PCI Express 3.0 x16 slot (1x 16 or 2x 8)
ane x PCI Express 2.0 x16 slot, running at x4
two x PCI Express 2.0 x1 slots
Storage:
i x 1000.2 connector M.2 type 2242/2260/2280/22110 SATA and PCIe x4 SSD support
one x G.2 connector M.two type 2242/2260/2280 PCIe x4 SSD support
6 10 SATA 6Gb/southward connectors support for RAID 0, RAID 1, and RAID 10
USB:
ASMedia USB 3.1 Gen 2 Controller:
1x Type-C port and i x Type-A port on the back panel
CPU:
4x USB 3.1 Gen 1 ports on the back console
Chipset:
1x USB Type-C port with USB three.1 Gen 2 support through the internal USB header
6x USB three.one Gen 1 ports (4 ports on the dorsum console, ii ports bachelor through the internal USB headers)
5x USB ii.0 ports (ii ports on the back panel, iii ports bachelor through the internal USB headers)
Sound:
ROG SupremeFX 8-channel with S1220 codec
Networking:
LAN Intel GbE LAN scrap (10/100/1000 Mbit)
WiFi/Bluetooth Wi-Fi 802.11a/b/k/n/air conditioning, 2.4GHz/5GHz Dual-Ring, Bluetooth 4.2
Form factor: ATX 305mm x 244mm
In our video we focus on voltage settings, power draw and performance as those are the aspects of the Asus ROG Crosshair VII Hero Wi-Fi that have changed with the BIOS, however it is well worth going around the other features i more than fourth dimension.
Some features volition appeal to mainstream users such equally the way the I/O panel is jam-packed with USB ports or the inclusion of high end 802.11ac Wi-Fi and Bluetooth. Other features are aimed squarely at the hardcore ROG customers, such as the multimeter points located next to the main 24-pin power connector or the micro buttons that requite you the tools y'all need to piece of work with the overclocking features in the BIOS every bit quickly and efficiently as possible.
There are no graphics outputs on I/O panel and it therefore follows the Asus ROG Crosshair Seven Hero Wi-Fi does not back up AMD APUs, even though they are pin compatible and will drop in the AM4 socket. This makes perfect sense to us as no-ane in their right mind would buy this motherboard and and then rely on integrated graphics.
Indeed, anyone ownership this motherboard is certain to be an enthusiast and when they install the Asus in a PC case they will exist pleased to find information technology sports eight four-pivot PWM fan controllers, which surely offers full control for any level of cooling you may desire.
In terms of styling and build quality the Asus ROG Crosshair 7 Hero Wi-Fi follows the usual grey and red theme with a lot of solid engineering science from the heatsinks on the VRMs with their linking heatpipe to the aluminium cover on the upper M.2 slot.
The Crosshair Vii Hero WiFi is an evolution of the X370 Crosshair VI Hero so there isn't much to see that is new. When we checked the VRM layout it became apparent the two VRMs directly below the power connectors control the SoC, which is unusual nevertheless perfectly sensible. In general the Vcore VRMs are bundled in an 50 shape and the SoC VRMs are positioned at the meridian of the board. The SoC leads an easier life than the Vcore then Asus has taken the novel approach of placing those VRMs at the hot spot in the angle of the L shape, which means the other VRMs take meliorate admission to cooling air.
We were taken ashamed by the beta of Asus Grid which is software that works in a like fashion to MSI Live Update and seems to exist triggered automatically past the BIOS. Put it this way, we didn't install Grid nevertheless at that place it was in Windows downloading drivers and getting the Crosshair Vii Hero gear up for activeness.
